Lamination line (Sandwich Bag)


Lamination specialized for producing Kraftpaper cement sack, BOPP film laminated with woven sack, and other technical fabrics. High level of coating technique provides smooth and even coating surface, which reduces material waste, while maintaining highest quality of coated fabric.

Specification
  • Automatic roll change system with max. machine running speed at 80 m/min
  • Line speed up to 150 m/min*
  • Gravimetric dosing unit as optional equipment
  • Edge trimming system
  • Modular machine concept
  • Customization upon request

* Depends on machine type, fabric and roll quality

Technical Data
Model Number lamXF 850D
Type Double side and sandwich
Application - woven sack
- woven sack + Kraft paper
- woven sack + BOPP film
Working Width
(single side)
400 - 850 mm
Operating Speed(max.) 150 m/min
Melting Capacity (max.) 320 kg/hour

* Machine specification depends on machine type, fabric type, application and roll quality
